| Output power RMS | |
| – @ 4 Ohms | HighPower mode: 4 x 60 Watts MidPower mode: 4 x 35 Watts |
| – @ 2 Ohms | – |
| – @ 1 Ohm | – |
| – bridged @ 4 Ohms | – |
| – bridged @ 2 Ohms | – |
| – Subwoofer output @ 4 Ohms | High- and MidPower mode: 1 x 90 Watts |
| – Subwoofer output @ 2 Ohms | High- and MidPower mode: 1 x 160 Watts |
| Amplifier technology | Class GD |
| Inputs | 4 x Highlevel speaker input 1 x Optical SPDIF (12 – 96 kHz) 1 x Remote in |
| Input sensitivity | 5 – 11 Volts |
| Input impedance RCA / Cinch | – |
| Input impedance highlevel | 9 – 33 Ohms with ADEP.3 |
| Outputs |
5 x Speaker output |
| Output voltage RCA / Cinch | 3 Volts |
| Frequency response | 20 Hz – 20,000 Hz |
| DSP resolution | 64 Bit |
| DSP power | 295 MHz (1.2 billion MAC operations/second) |
| Sampling rate | 48 kHz |
| DSP type | Audio signal processor |
| Signal converters |
A/D: BurrBrown |
| Signal-to-noise ratio digital input | > 105 dB (A-weighted) |
| Signal-to-noise ratio analog input | > 99 dB (A-weighted) |
| Distortion (THD) | < 0.03 % |
| Damping factor | > 50 |
| Operating voltage | 10.5 – 17 Volts (max. 5 sec. down to 6 Volts) |
| Power rating | DC 12 V ⎓ 40 A max. |
| Idle current | 280 mA |
| Max. remote output current | 500 mA |
| Operating temperature range | -40° C to +70° C |
| Fuse | 1 x 30 A Maxi-fuse (APX) |
| Additional features | 32 Bit CoProcessor, ADEP.3 circuit, Auto Remote switch, Smart Control Port, Start-Stop capability, USB |
| Dimensions (H x W x D) | 35 x 85 x 110 mm / 1.34 x 3.35 x 4.33″ |
